BDCOM S2500PB Series Full Gigabit POE Switches, L2 managed

Intelligent POE access switch designed for carrier’s IP MAN and enterprise networks.

L2 managed

Description du produit

Product Overview

BDCOMS2500PB Series is a new-generation intelligent POE access switch designed for
carrier’s IP MAN and enterprise networks. Based on the new-generation
high-performance hardware and BDROS platform, it supports functions such as
ACL, QinQ and QoS. Its simple management mode and flexible installation can
meet the requirement of any complicated scenarios.

BDCOM
S2500PB Series POE switches has three models: S2510PB, S2518PB and S2528PB.

l  S2510PB: 8 10/100/1000Base-T ports, 2
1000Base-X ports;

l
S2518PB: 16
10/100/1000Base-T ports, 2 1000Base-X ports;

l
S2528PB: 24
10/100/1000Base-T ports, 4 1000Base-X ports.


Product Characteristics



Ø Telecom-Level Ethernet Access Switches

l  S2500PB
Series
supports the
telecom-level Ethernet-ring protection protocol with a protection shift time of
less than 50ms, STP/RSTP, backup of active and standby uplinks, and LACP link
aggregation to cater to the requirements of high reliability of carriers;

l  S2500PB
Series
has powerful ACL
functions to access and control L2-L7 data based on physical port, providing
carriers flexible and various policy control methods;

l  S2500PB
Series
supports In-Service
Software Upgrade (ISSU) to ensure the unremitting data forwarding during system
upgrade;

l  S2500PB
Series
supports various L2
multicast functions such as IGMP-snooping, user fast-leave mechanism and
trans-vlan multicast copy to fully meet the operation requirements of carrier’s
IPTV;

Ø
Complete POE Power Supply

l  S2500PB
Series supports IEEE 802.3AF/AT standard, built-in large power supply, free of
external power supply, that is, 24-port AF full load power supply;

l  S2500PB
Series supports hot restart and POE non-stop power supply;

l  S2500PB
Series supports the configuration of TX port priority when the power is
inadequate.

l  S2500PB
Series supports up to 2KV thunder-proof of the POE port and power supply

Ø  Varied
QoS Policies

l  S2500PB
Series
supports priority
retagging and complicated flow classification based on VLAN, MAC, source
address, destination address, IP or priority, better streamlining carrier’s
services;

l  S2500PB
Series
provides flexible
bandwidth control policies, supporting port-/flow-based flow limit, ensuring
the line speed forwarding of each port;

l  S2500PB
Series
supports multiple queue
schedule algorithms such as SP, WRR and “SP plus WRR”;

Ø
Complete
Security Mechanisms

l  Equipment-level
security: The advanced hardware infrastructure design realizes the level-based
packet schedule and packet protection, prevents DoS-/TCP-related SYN Flood, UDP
Flood, Broadcast Storm or large traffic attacks, and supports level-based
command line protection, endowing different levels of users with different
management permissions;

l  Perfect security
authentication mechanisms: IEEE 802.1x, Radius and BDTacacs+;

l  S2500PB
Series
supports storm/multicast/unicast
limit, ensuring the normal running of equipment in harsh network conditions;

l  S2500PB
Series
supports perfect ring
detection mechanism, ensuring the long-term stable running of network;

l  S2500PB
Series
supports port isolation
within the same VLAN, DHCP-Snooping, and IP + MAC + Port binding;

Ø
Easy
Management and Maintenance

l  S2500PB
Series
supports many
management modes such as the console port, Telnet, SSH;

l  S2500PB
Series
supports the WEB management
mode, which is easy and efficient for installing and debugging the device;

l  S2500PB
Series
supports TFTP-patterned
file upload/download management;

l  S2500PB
Series
supports ISSU
(In-Service Software Upgrade);

l  S2500PB
Series supports SNMP and BDCOM NMS smart network management platform. The
combination realizes automatic equipment discovery, network topology
management, equipment configuration management, performance data statistics and
analysis and trouble
management.




Specifications

Item

S2510PB

S2518PB

 S2528PB

Backplane

18Gbps

64Gbps

64Gbps

Forwarding rate

15Mpps

27Mpps

42Mpps

Dimensions(W×D×H)(mm)

280×179×45

440×232×4

440×232×45

Power consumption

30W

45W

45W

POE power

150W

330W

400W

POE/POE+

Support

Support

Support

Power supply

AC: 100V-240V, 50Hz±10%

DC: -36V~-72V (POE model without
DC power supply)

Environment

Operating temperature/humidity: 0-50,10%-90% non-condensing

Storage temperature/humidity: -20-70, 5%-95% non-condensing

MAC exchange

Static configuration and dynamic
MAC learning

MAC browsing and removal

Configurable aging time of the MAC
address

Limited number of learnable MAC
addresses

MAC filtration

VLAN

4K VLAN

GVRP

QinQ

Private VLAN

STP

802.1D (STP), 802.1W (RSTP) and
802.1S (MSTP)

BPDU protection, root protection,
and loopback protection

Multicast

IGMP v1/v2/v3

IGMP Snooping

IGMP Fast Leave

Multicast group strategy and
quantity limitation

Multicast flow copying over VLANs
(S2108POE does not support the function.)

IPv4

Static route, RIP v1/v2, OSPF, BGP

QoS

Flow classification based on L2~4
protocols (S2108POE does not support)

CAR flow limit

802.1P/DSCP priority re-labeling
(S2108POE does not support)

SP, WRR, and “SP+WRR”

Congestion avoidance mechanisms
like Tail-Drop and WRED

Flow monitoring and flow shaping

Security

L2/L3/L4 ACL flow identification
and filtration (S2108POE does not support the function.)

DDoS attack prevention, TCP’s SYN
Flood attack prevention, UDP Flood attack prevention, etc

Broadcast/multicast/unknown
unicast storm-control

Port isolation

Port security, and “IP+MAC+port”
binding (S2108POE does not support.)

DHCP Snooping and DHCP option 82
(S2108POE does not support the function.)

IEEE 802.1x authentication

Radius, BDTacacs+ authentication

Level-based command line
protection

Reliability

Static/LACP link aggregation

EAPS and ERPS (S2108POE does not
support the function.)

ISSU uninterrupted system upgrade

Management

Console, Telnet, SSH2.0, Web

SNMP v1/v2/v3

TFTP

RMON

Ordering Information

Item

Description

S2510PB
Series POE Switches

S2510PB

Ethernet POE switch with 8 gigabit
TX ports and 2 gigabit optical ports (1 Console port, 8 gigabit POE TX ports,
2 gigabit optical ports, standard AC220V power supply, 150W POE power, the
cooling fan, 1U, desktop installation)

S2518PB

Ethernet POE switch with 16 gigabit
TX ports and 4 gigabit optical ports (1 Console port, 16 gigabit POE TX
ports, 2 gigabit SFP ports, standard AC220V power supply, 330W POE power, the
cooling fan, 1U, standard 19-inch rack-mounted installation)

S2528PB

Ethernet POE switch with 24
gigabit TX ports and 4 gigabit optical ports (1 Console port, 24 gigabit POE
TX ports, 4 gigabit SFP ports, standard AC220V power supply, 400W POE power,
the cooling fan, 1U, standard 19-inch rack-mounted installation)
