TS-SG1008-P PoE Switch with 8 Gigabit ports+1 SFP

High Power PoE  Gigabit Ethernet Switch  with features IEEE 802.3af and IEEE 802.3at  96/120-watt PoE

8ports RJ45  10/100/1000Mbps + 1extra 10/100/100Mbps RJ45 and 1 extra 1.25Gbps SFP slots can be used for uplink.

Description du produit

Ø Overview

To fulfill the demand of High Power PoE for network applications with Gigabitj transmission, TS-SG1008-P PoE Gigabit Ethernet Switch is an ideal solution. Each 10/100/1000Mbps port of the TS-SG1008-P features IEEE 802.3af and IEEE 802.3at Power over Ethernet (PoE) that combine up to 96/120-watt PoE budget on the whole system.

 All RJ45 copper interfaces of the TS-SG1008-P support 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ45 Category 6, 5 or 5e cables. It also supports standard auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables. 1 extra 10/100/100Mbps RJ45 and 1 extra 1.25Gbps SFP slots can be used for uplink.



Typical applications please refer to following picture

Features

l  Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T

l  8-Port 10/100/1000Mbps supports 52V DC power to PoE Powered Device

l  1-Port 10/100/1000Mbps RJ45 interface for uplink

l  1 1.25Gbps SFP interface for uplink

l  Complies with IEEE 802.3af/802.3at Power over Ethernet End-Span PSE

l  Up to 8 IEEE 802.3af devices powered

l  Supports PoE Power up to 15.4 watts for each PoE port

l  Up to 4 IEEE 802.3at devices powered

l  Supports PoE Power up to 30 watts for each PoE port

l  96/120-watt PoE budget

l  Auto detects powered device (PD)

l  Circuit protection prevents power interference between ports

l  Remote power feeding up to 100m

l  Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X

l  Features Store-and-Forward mode with wire-speed filtering and forwarding rates

l  IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation

l  Integrates address look-up engine, supporting 8K absolute MAC addresses

l  2M packet buffer

l  10K Jumbo frame supports at 1000Mbps duplex mode

l  IEEE 802.1Q VLAN packet transparency support

l  Automatic address learning and address aging

l  Made of metal, desktop size and wall-mount design

 Technical Specifications



Item

Description

Model

TS-SG1008-P

Power Supply

Power Supply Mode

 Mains on
load

Voltage Range

AC 100240V

Power Consumption

The device <5W
POE power supply <96/120W

Network Port Parameter

Network Ports

 18
Ports: 10/100/1000Mbps Ethernet port, adaptive control

Uplink 1 SFP:1.25Gbps and 1 10/100/100Mbps RJ45

Transmission Distance

1~8 Ethernet Port0~100m

Mandatory 10 Mbps reach up to 250m

1 uplink Ethernet Port0~100m

1 SFP: According to different SFP

Transmission Media

1~8 Ethernet PortCat5e/6 standard UTP cable

2 SFP: LC interface optical fiber

POE Agreement

IEEE802.3 af/at standards

PoE Power Supply Mode

End-span method

PoE Power Supply Wattage

Each port≤30W,Whole device<96/120W

Network Switch Specification

Network Standard

IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX,
IEEE802.3ab 1000BASE-T

Swap Mode

Store-and- forward

Switch Capacity

20Gbps

MAC Address List

8K

Status Indicators

Power Indicator Light

One power light green

Optical Fiber Port Indicator

One fiber link indication light ( green), Green
light keeps on when the fiber port is well connected; Blinking when
transceiver data

PoE Indicator

1~8 PoE indicator lightyellow

PoE Network Port LED

1~8 port ( green light on RJ45 jack) Keeps on
when normally connected, Blinking when transceiver data

Protection Level

Surge Immunity

Level 3, executive standardIEC61000-4-5

Electrostatic Protection

1a touch electric discharge: level 3

1a Air discharge: level 3

Executive standardIEC61000-4-2

Operating Environment

Working Temperature

-10℃~55

Storage Temperature

-40-85

Humidity(non-congeal)

0~95%

Mechanical Attributes

Dimensions (L*W*H)

188.5mmx102.5mmx28.25mm

Color

Black

Weight

1.5kg

Reliability

Mean time between failures MTBF

50000h
