Managed industrial switch for harsh environments, 8 Gigabit POE+ ports, 2 Gigabit SFP slots, isolated power supply (44-57VDC), IP40 protection grade.

Catégorie :

Product Description

Since the turn of last century, MRD™ industrial communication products have been deployed all around the world. TOM1000 series can be seen in the harsh environment of each and every industrial sector. As one of the low cost and high reliability solutions to connect terminal devices to network, TOM1000 full Gigabit POE series industrial Ethernet switches show remarkable features such as high electromagnetic immunity and anti-shock & anti-vibration ability based on the extended industrial design. TOM1000 full Gigabit POE supports up to 8 POE ports and each POE port provides up to 30W output power. TOM1000 POE can effec- tively solve the centralized power supply for IP phones, wireless APs, security cameras and other terminal devices, thus TOM1000 full Gigabit POE has been widely used in the corporate and industrial applications. Most models of TOM product line support plug & play, you simply plug in power & cable, and you are ready to go. TOM1000 series utilize FPGA and CPLD dynamic reconfiguration and replicate programming technolo- gy for high stability and reliability, Advanced solution, extended industrial design, and patented technologies make TOM1000 one of the top choices for harsh industrial environments. Conformal coating can also be re- quested for extra humidity, dust, and corrosion protection.
  • Layer 2 linear switch with high performance and flexible configuration
  • Support up to 52Gbps backplane bandwidth
  • Support MRD-RING® Media Redundan- cy Protocol (compliant with IEC62439)
  • Support up to 8 POE ports
  • Support 802.3af/at compliant POE
  • Each POE port provides up to 30W output power
  • POE management: POE device detection,
  • POE power management
  • Managed models support Web/ssh/snmp management interface to display the status and detailed statistics of 10 Gigabit ports in full load
  • Support the firewall function based on MAC, IP or port ID
  • Support storm control
  • Support port-based CoS
  • Built-in unified ATLANTIS embedded real- time system
  • Dual redundant power inputs design for DC models
  • Fanless, -40 to 75°C wide operating tem- perature range
  • MTBF >400, 000 hours

Hardware Description

Backplane Bandwidth:




Switch Architecture:


MAC Table Size:




Exchange Rate:

1, 488, 000 pps/1000M ports

Software Functions

Management Mode:

Web, STD-17 MIB-II, STD-58 SMIv2, STD-59 RMON, STD-62 SNMPv3, SNMPv2c, SNMPv1, RFC2668 MAU, RFC2925 Ping MIB, MRD Private MIBs,

SSH, HTTPS, Telnet

Diagnosis Mode:

Indicator light, journal file, RMON, port mirroring, TRAP


RSTP, STP, MSTP, MRD-Ring®, port trunking

Time Synchronization:



4K VLANS, IPv4/IPv6 multicast, storm control, support Jumbo Frame

Physical Performance


> 400, 000 hours

Storage Temperature:

-40°C~ 85°C

Operating Temperature:

-40°C~ 75°C

Ambient Relative Humidity:

5% ~ 95% (non-condensing)

Dimensions (W x H x L):

8 Gigabit POE ports: 156mm x 42mm x 170mm

Protection Grade:



0.6KG (Maximum)

Power Consumption:

10W (Maximum)
