Heater 100w / Heater 150w – Résistance Chauffant

Resistance pour coffret exterieur 100WATT et 150WATT

Utilisé afin d’éviter la condensation d’humidité dans les coffrets quand la temperature baisse.

Doit être utilisée avec thermostat chaud pour regler la temperature de demarrage.

Product Description

These heaters are used in enclosures where damage from condensation must be prevented, or where the temperature may not fall below a minimum value. The aluminium profile heater body design has a chimney effect and distributes the heat evenly. The heaters are designed for permanent operation. Pressure clamb connectors save time and simplify installation. Available capacities are 100w and 150w.
  • Pressure clamp connectors
  • Dynamic heating up
  • Wide voltage range
  • Energy saving
  • Clip fixing, Quick installation
Models: Heater100w and Heater150w
Capacities: 100w and 150w
Operating voltage 120-240V AC/DC1(min.110V,max.265V)
Heating element PTC resistor-temperature limiting
Heater body extuded aluminium profile,anodised
Connection 3 pressure clamps for stranded wore 0.5-1.5mm2 (with wire end ferrule) and rigid wire 0.5-2.5mm2
Connection casing plastic according to UL94V-0,black
Mounting clip for 35mm DIN rail, EN 60715
Fitting position vertical airflow(air outlet up,connection on botton)
Operating/Storage temperature -45 to +70℃(-49 to +158℉)
Operating/Storage humidity max.90%RH(non-condensing)
Protection type/Protection class IP20/I(earthed)
Accessoires screw fixing,Art.No.09024.0-00(1 packing unit=2 pieces)
Note other voltages on request
