Used for regulating heat exchangers or fan filters.

The contact closes when temperature is rising.

Product Description

Thermostat (normally open); contact maker for regulating of filter fans and heat exchangers or for switching signal devises when temperature limit has been exceeded. The contact closes when temperature is rising.
  • Large setting range
  • Small size
  • Simple to mount
  • High switching performance
Switch temperature difference +/-5°C
Sensor element thermostatic bimetal
Contact type snap-action contact
Service life > 100,000 cycles
Max. switching capacity

250VAC, 10 (2) A / 120VAC, 15 (2) A

DC 30W at 24VDC to 72VDC

Max. inrush current AC 16A for 10 sec.
Connection 2-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm² (AWG 14) stranded wire¹ 1.5mm² (AWG 16)
Mounting clip for 35mm DIN rail, EN 60715
Casing plastic according to UL94 V-0, light grey
Dimensions 60 x 33 x 43mm
Weight approx. 40g
Fitting position variable
Operating/Storage temperature -45 to +80°C (-49 to +176°F)
Operating/Storage humidity max. 90% RH (non-condensing)
Protection type IP20
