TS-IF2F8

Switch industriel non manageable, non POE, avec 8 10/100/1000Base-TX ports+2 Gigabit SFP (Alimentation non incluse)..

Support alimentation 9VDC-à-36Vdc quand utilisé sans POE

Supporte la vitesse 10MBps sur les ports Rj45

Catégorie : Étiquettes : ,

Product Description

TS-IF2F8:

Industrial Switch with 8 10/100/1000Base-TX ports+ 2 Gigabit SFP, non POE ( sans alimentation)

Product Description:

TS-IF2F8 is an Industrial Ethernet Switch, which can provide economical solution for your Ethernet.

Its dustproof fully sealed structure (pr protective case of IP30 level), over-current, over-voltage and EMC protected wide power input, which can work reliably in harsh and dangerous environment.

It provides 8 10/100/1000Base-TX ports and 2 Gigabit SFP ports.

  1. Conforms to IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE802.3af, IEEE802.3at
  2. Provides 8 10/100/1000Base-TX ports and 2 Gigabit SFP ports
  3. High back-plane bandwidth 5.6Gbps
  4. Surge protection for power port and data ports
  5. Wide power input: 44V~57VDC
  6. Wide working temperature: -40~70℃
  7. IP30 DIN-Rail mounting metal case
  8. 200,000 hours MTBF (Parts count reliability prediction)
                 Item                                   Description
Summarize
Fixed port 8 10/100/1000Base-TX ports.

2 Gigabit SFP ports.

LED Indicators PWR, PoE and Link/Act LED.
Input voltage 44V~57V DC
Power consumption ≤15W(For Switch Part)
Operating temperature -40℃~70℃
Storage temperature -40℃~70℃.
Relative humidity 5%~95% (non-condensing).
Process View Support.

Download:

TS-IF2F8_Datasheet: PDF
