40G QSFP+ to 4x10G SFP+ Breakout Active Optical Cable 1-30m

Product Description

Description

A family of QSFP+ to 4xSFP+ breakout active optical cables (AOC) for the interconnect between 40G Ethernet (40GbE) and 10G Ethernet (10GbE) applications., which is also known as QSFP+ splitter AOC or QSFP+ Fan-out AOC. The QSFP+ to 4x SFP+ breakout AOC offers four parallel, bi-directional channels each operating at up to 10.3125 Gbps. Using industry-leading VCSEL technology, an advanced new light-engine design and bend-insensitive multimode fiber, this AOC delivers exceptional cost and performance value for 10 and 40GbE applications at distances up to 100 meters.

Features

• Supports 40G to 10G Ethernet interoperability
  • SFF-8436 QSFP+ compliant
  • SFF-8431 SFP+ compliant
  • 4 channels 850nm VCSEL array
  • Less cabling to order and manage
  • Available in lengths of 1m to 100m
  • Small cable bend radius
  • 3.3V power supply voltage
  • Low power consumption< 1.5W
  • Operating case temperature: 0 to 70℃

Specification
