Managed Industrial Fiber Switch, 2 x 1000Mbps SFP fiber ports, 16 x 10/100/1000Mbps TX RJ45 ports

Catégorie :

Product Description

TS-IMF2G16 series is the 10/100/1000 Mbps industrial fiber switch, operating temperature-40 ℃to + 85℃, support wide voltage dual power input, meet IP30 protection degree and EMC industrial grade requirements, support many managed functions, include RSTP IGMP, VLAN, Qos, IPV6, Loop protection, ERPS and so on. pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.

  • 16 x 10/100/1000Mbps Auto-sensing TX RJ45 ports
  • 2 x 1000Mbps SFP fiber ports
  • Support cable diagnosis and can locate the fault point
  • Support IEEE802.3az EEE (Energy Efficient Ethernet) Management, optimize power consumption
  • Support STP, RSTP, MSTP, ITU-T G.8032 Ethernet Protection Ring(EPR)
  • Support Qos, transport classification Qos, Cos, bandwidth control (input/output direction), storm suppression ,differentiated services
  • Support IEEE802.1q VLAN,VLAN port ,based Mac VLAN,IP subnet VLAN, Protocol VLAN,VLAN convert, MVR
  • Support dynamic IEEE802.3ad LACP link aggregation, static link aggregation
  • Support IGMP/MLD snooping V1/V2/V3, IGMP filtrating/ modulating, IGMP searching
  • Support IGMP agent report, MLD snooping
  • Safety: based on port and Mac IEEE802.1X, RADIUS, ACL, TACACS+,HTTP/HTTPS, SSL/SSH v2
  • Support Cisco® like CLI, Web management, SNMP v1/v2c/v3, Telnet
  • Support software upgrade via TFTP and HTTP, firmware redundancy prevents upgrade failing
  • Support DHCP client/Relay/Snooping/Snooping option 82/Relay option 82
  • Support RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, IEEE802.1ab LLDP
  • Support IPV6 Telnet server /ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP,TFTP, QoS, ACL.

Product Name

10/100/1000Mbps Industrial  Fiber Switch (2F+16TP)

Model No.



2 x 1000Mpbs SFP ports

16×10/100/1000M UTP RJ45


IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az



Jumbo Frame


MAC Address Table Size


Poe Standard

IEEE802.3af, IEEE802.3at ( Poe is optional, default is without Poe)

Switching features

Transmission modestorage and forward

System bandwidth48Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP porttransmission distance: 20Km40Km60Km80Km100Km


Power, network, fiber

Power supply

Input voltageDC 9-52V

Non-polar power input support


Working temperature-40° 85°C

Working humidity5%95%non-condensing

Industry Standards

EMIFCC Part 15 Subpart B Class AEN 55022 Class A, EN61000-6-4- Emission for industrial environment

EMSEN61000-6-2-Immunity for industrial environment, EN 61000-4-2 (ESD) Level 3EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3EN 61000-4-8

Traffic ControlNEMA-TS2, VibrationIEC 60068-2-6

FreefallIEC 60068-2-32, ShockIEC 60068-2-27

Rail TrafficEN 50121-4

Mechanical information

Safety classIP30

Dimension483x 275 x 44.5mm


Replacement within 1year; 5 years repairing
