CONVERTISSEURS FO SM,SC dual fiber, 10/100/1000Mbps, distance 40-80Km , long d’onde  1550nm.

Product Description

TS-MC410SM / TS-MC810SM are  10/100/1000Mbps adaptive Gigabit Ethernet media converters adopts switching technology to fulfill media conversion.

It complies with IEEE802.3, IEEE802.3u, IEEE802.3z and IEEE802.3ab standards.

Presently it supports two types of media network connections: 10Base-T/100Base-TX/1000Base-T, and 1000Base-SX, inter-converting electrical signals of 10Base-T/100Base-TX/1000Base-T twisted pairs with optical signals of 1000Base-SX.

It extends the transmission distance of network via copper cable to 40km via fiber optical cable. It supports transmission in single-mode dual fiber

  1. According to IEEE802.3, IEEE802.3u, 10/100Bast-TX, 100Base-FXstandard. Support IEEE802.3X flow control function.
  2. Ethernet port support10/100M, full-duplexand semi duplex auto-negotiation.
  3. Ethernet port Auto-MDI/MDIX auto flip, parallel/across twisted-pair auto-negotiation.
  4. Support storage transmission and direct transmission.
  5. Ultra-low time-delay data transmission, completely transparent to the net work protocol.
  6. Link failure alarm(LFP) function.
  7. Built-in128K BRAM data buffer, support 1600 Bytes long data packet.
  8. 9/125um single mode fiber link transmission distance up to 40KM.
  9. Modulation configuration design, chassis support power supply for cassette media converter.
  10. Support hot-swappable, plug and play.
  11. 6LED indicator, dynamix feed back link connection state and fault detection.
  12. Built-in 8bit DIP switch, user's easily adjust the various of transmission and working mode (intelligence Type).
  13. Built-in lightning protection circuit, significantly reduce the damage caused by thunderbolt induction.
  14. Average working time more than100,000 hours without failures.



 Access mode

 10/100/1000Mbps Gigabit Ethernet


 IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE802.3ab 1000Base-T ,

 IEEE802.3z 1000Base-SX Gigabit Ethernet

 Wavelength (Monomode)


Single mode: 8.3/125, 8.7/125, 9/125or10/125µm

 Transmission distance (Monomode)



 One RJ45 port:

 Connecting with STP/UTP category-5 twisted pairs, EIA568A/B

 One optical port:




 100,000 hours

 LED indicator

 POWER (power supply), FX LINK (optical link action)

 TP LINK1000 (TP cable rate1000M), TP LINK100 (TP cable rate 100M)

 TP ACT (TP cable packet forwarding action), FDX (TP full duplex operation)

 Power supply

 External: AC90~264V/DC100~380V input, 5V 2A output

 Power consumption

 Max. 5W

 Operating temperature


 Operating humidity


 Maintaining temperature


 Maintaining humidity

 5% ~ 90% non-condensing


 71mm (W)×94mm (D)×26 mm (H) (external power supply)

  • Only one converter per carton


_ TS-MC410SM_Datasheet: PDF

_ TS-MC810SM_Datasheet: PDF
